Clark GTS25D 2.5t 2WD Diesel Masted Forklift
The Clark GTS25D is a robust and reliable forklift designed for efficient material handling. With its compact dimensions, it provides excellent manoeuvrability in tight spaces, making it ideal for construction sites. Enhance your productivity with this powerful machine tailored for demanding environments.
Item ID: 50002751
Reference: 026010
Basic Dimensions
Length (mm)3740
Height (mm)2160
Width (mm)1190
Weight (kg)3840
Environmental & Sustainability
Average Usage Emissions Per Operating Hour (ERA)11.7
Average Consumption Per Operating Hour (ERA)3.7
Average Engine Operating Hours Over A Rental Day (ERA)3.2
Power Source
Power Source / Fuel TypeDiesel
Voltage - System (V)12
Engine MakeYanmar
Engine Model4TNE98
Power - Engine (max) (kW)46 - 59
Power - I.C. Engine Rating (hp)34.3 - 44.3
Safety Information
Vibration - Hand-Arm (m/s2)2.5
Sound Pressure (dB)80.5
Technical Dimensions
Height - Lifting (max) (m)3.19
Size - Tyres7.00X12-14PR P (Front) / 6.00X9-10PR (Rear)
Height - Cab Overhead Guard (mm)1200
Load Centre (mm)500
Load Spacing (mm)450
Length - Fork (mm)2670
Length - To Face of Fork (mm)1040
Radius - Turning (Range) (m)0.83 (Inside) / 2.38 (Outside)
Height - Seat/Stand (mm)360
Height - Tow Bar Coupling (mm)1070
Ground Clearance - Range (mm)150
Wheelbase - Range (m)1.62 - 2.17
Technical Specifications
Capacity - Lifting (kg)2500
Handling OperationsDriver Seated
Transmission Type1 Forward / 1 Reverse Split transmission
Capacity - Fuel Tank (L)52
Capacity - Hydraulic Tank (L)55
No. of Cylinders4
Gradeability (%)17.4 - 32.1
Cooling SystemLiquid
Tyres TypePneumatic
Speed - Travel (Range) (mph)10 - 11
Speed - Lifting (Range) (m/sec)0.48 - 0.54
Speed - Lowering (Range) (m/sec)0.5 - 0.54
Weight - On Front Axle (Laden/Unladen) (kg)5450 / 1476
Weight - On Rear Axle (Laden/Unladen) (kg)890 / 2364
No. of Drive Wheels2x/2
Pull - Drawbar (Laden/Unladen) (daN)18470 / 6135
Service Brake TypeWet disc brake
Speed - Rated (Range) (rpm)2200 - 2300
