Clark C 30 CL 3t 4WD Diesel Industrial Forklift
The Clark C30CL is a robust and reliable forklift, designed for efficient material handling in various settings. Its compact dimensions ensure manoeuvrability in tight spaces, making it ideal for construction sites. Experience superior performance and durability with this exceptional machine.
Item ID: 50002757
Reference: 026174
Basic Dimensions
Length (mm)3740
Height (mm)2180
Width (mm)1240
Weight (kg)4189
Environmental & Sustainability
Average Usage Emissions Per Operating Hour (ERA)15.2
Average Consumption Per Operating Hour (ERA)4.8
Average Engine Operating Hours Over A Rental Day (ERA)3.2
Convenience Features
Reverse LightsYes
Side-Entry CabYes
SeatYes
Power Source
Power Source / Fuel TypeDiesel
Voltage - System (V)12
Engine MakeYanmar
Engine Model4TNE98
Power - Engine (max) (kW)44.3
Power - I.C. Engine Rating (hp)59
Engine Start SystemElectric starter (12V system)
Safety Information
Operator HornYes
Service BrakeYes
Parking BrakeYes
Noise Level (dB)79
Sound Pressure (dB)81
SeatbeltYes
Reverse Warning AlarmYes
Technical Dimensions
Height - Lifting (max) (m)3.3
Size - Tyres28X9x15 -14PR (Front) / 6.50x10-12PR (Rear)
Lift - Free (m)0.11
Height - Overall (Mast Extended) (mm)3897
Height - Mast Retracted (mm)2180
Height - Cab (mm)2180
Height - Cab Overhead Guard (mm)1130
Load Centre (mm)500
Load Spacing (mm)450
Length - Fork (mm)2670
Length - To Face of Fork (mm)1040
Width - Fork (mm)122
Thickness - Fork (mm)45
Radius - Turning (Range) (m)2.41
Width - Required in Aisle (m)4.26
Height - Seat/Stand (mm)410
Height - Tow Bar Coupling (mm)1070
Gauge - Wheel (Front/Rear) (m)3.3
Ground Clearance - Range (mm)150
Wheelbase - Range (m)1.7 - 2.18
Technical Specifications
Capacity - Lifting (kg)3000
Handling OperationsDriver Seated
Capacity - Fuel Tank (L)51.9
Capacity - Hydraulic Tank (L)44
No. of Cylinders4
Displacement (L)2.35
Gradeability (%)19.4 - 33
Cooling SystemAutomotive type crossflow radiator
Tyres TypePneumatic
Angle - Tilt-Up (°)10
Angle - Tilt-Down (°)8
Speed - Travel (Range) (mph)12 - 13
Pressure - Working (bar)140
Speed - Lifting (Range) (m/sec)0.54 - 0.65
Speed - Lowering (Range) (m/sec)0.43 - 0.47
Gearbox TypeHydrodynamic / continuous (powershift)
Weight - On Front Axle (Laden/Unladen) (kg)6372 / 1687
Weight - On Rear Axle (Laden/Unladen) (kg)816 /2502
Load - On Forks (Nominal) (t)3
No. of Drive Wheels2 Forward / 2 Reverse 2X /2
Pull - Drawbar (Laden/Unladen) (daN)22082 / 9928
TractionHydrodynamic drive via powershift transmission (drive axle traction)
Service Brake TypeDrum and Shoe
Speed - Rated (Range) (rpm)2400
