Genie GS2669 DC 26' Electric Scissor Lift RT
The Genie GS-2669 DC is a robust and reliable scissor lift, designed for optimal performance in indoor and outdoor construction tasks. Its compact size enables easy manoeuvrability, making it perfect for tight spaces. Elevate your productivity with this powerful lifting solution.
Item ID: 50000021
Reference: 075251
Basic Dimensions
Length (m)3.12
Width (m)1.75
Height (m)2.59
Weight (kg)3442
Environmental & Sustainability
Sound Pressure (dB)70
Convenience Features
All Motion AlarmYes
Non Marking TyresYes
Power To CageYes
Proportional ControlsYes
All-Wheel SteeringNo
Extended PlatformYes
Fold Down Hinged Railing SystemYes
Self Locking GateYes
OutriggersYes
Dual Flow HydraulicsNo
HourmeterYes
Lifting Check ValvesYes
Manual DescentYes
Oscillating Axle ChassisYes
Proportional Direct DC Electric DriveYes
Proportional Lift UpYes
Quad Holding BrakesNo
Single Pump HydraulicsYes
Slide-Out Engine TrayNo
Tilt SensorYes
Power Source
Power Source / Fuel TypeElectric
Battery (V/Ah)8x 6V / 225Ah
Voltage (V)48
Safety Information
Flashing BeaconNo
Harness RingsYes
HornYes
Tilt AlarmYes
Vibration Level (m/s2)2.5
Dual Holding BrakesYes
Emergency Stop ButtonYes
Overload Sensing SystemYes
Technical Dimensions
Area - Platform (m²)4.464
Ground Clearance (m)0.24
Height - Drive (m)7.92
Height - Guardrail (m)1.47
Height - Stowed (m)2.59
Height - Working (m)9.7
Length - Platform (m)2.79
Size - Tyre12 x 26
Turning Radius - Inside (m)2.11
Turning Radius - Outside (m)4.6
Wheelbase (m)2.29
Width - Platform (m)1.6
Height - Hand Rails Down (m)1.92
Height - Platform (m)7.92
Height - Working (max) (m)10
Deck Extension (m)1.52
Technical Specifications
Capacity - Hydraulic Tank (L)68.1
Gradeability (%)35
Load - Safe Working (kg)680
Load - Wheel (max) (kg)1538
No. of Lifting Eyes2.59
No. of Persons (Max)4
Pressure - Per Tyre Contact (psi/kPa)84.8 /584
Slope (Max) (%)35
Speed - Drive (Elevated) (mph)0.31
Speed - Drive (Lowered) (mph)4.47
Speed - Falling (Loaded) (s)31
Speed - Rising (Loaded) (s)34
Speed - Wind (max) (mph)27.9
Tyre TypeNon Marking Rough Terrain
Charger TypeOn‑board automatic battery charger
Drive TypeElectric, 48 V direct electric drive, Two‑wheel drive with oscillating axle
Output - Power48 V DC
Hydraulic SystemElectro‑hydraulic system,
Capacity - Distributed (Extension Deck) (kg)136
Capacity - Distributed (Main Platform) (kg)680
Capacity - Total (kg)680
Weight - Total Aerial Platform (max) (kg)3604
