FPM FG-LL31+ Laser Plummet
The FPM FG-LL31+ is a versatile and reliable piece of equipment, perfect for construction tasks. Its robust design ensures durability, while its compact dimensions make it easy to transport and manoeuvre on site. Ideal for both professionals and DIY enthusiasts, this model delivers exceptional performance.
Item ID: 50001043
Reference: 190030
Basic Dimensions
Weight (kg)3.4
Height (mm)255
Length (mm)172
Convenience Features
Features
- Fully automatic: Automatic levelling and cut-out in case of low battery or jerky movement.
- Undervoltage lock-out
- LCD Display: bright display, instrument data, company data, battery status and menu.
- Lithium Ion Battery: up to hrs operating time, battery charges in 5 hrs max.
- Can be automatically switched off: Tilt over fix points is possible
- Special laser beam quality: Diode laser with visible beam, high-performance optics, high performance expectancy and low power consumption.
- High safety: Control indicators with blinking warning system for levelling, operating status and low battery.
- Uncompromisingly easy: All you have to do is switch on/off. The rest is carried out automatically.
Pendulum LockNo
Plumb DownNo
Plumb UpYes
Sleep ModeNo
Smart SlopeNo
Power Source
Power Source / Fuel TypeBattery
Battery Life45 hours
Battery TypeLithium
Voltage (V)11
Output - PowerLaser Output: less than 5mW
Safety Information
Temperature - Operating (°C)-10 to +50
Technical Dimensions
Accuracy - Horizontal/Vertical Line+/- 5 mm / 100 m
Range - Operating (m)500
Technical Specifications
Purpose/Made forConstruction
Time - Charging (hrs)5 hours max.
Direction - BeamZenith (Up)
Laser Class3 R, visible, red
Laser Diode (nm)635
Range - Self-Levelling (%)+/- 5
Accuracy - Grade+/- 5 mm / 100 m
