Skyjack SJ12 18' Electric Vertical Mast Lift
Basic Dimensions
Length (m)1.37
Width (m)0.76
Weight (kg)782
Environmental & Sustainability
Sound Power (dB)70
Convenience Features
All Motion AlarmYes
Descent & Travel AlarmYes
Non Marking TyresYes
Power To CageYes
Proportional ControlsYes
All-Wheel SteeringNo
Dual Wheel BrakesYes
Fold Down Hinged Railing SystemNo
Fork PocketsYes
Hydraulic Brake ReleaseYes
On Board Diagnostic SystemNo
Work Station TrayNo
Power Source
Power Source / Fuel TypeElectric
Battery TypeLeadAcid
Battery (V/Ah)240Ah
Voltage (V)24
Safety Information
Flashing BeaconNo
Harness RingsYes
Tilt AlarmYes
Technical Dimensions
Area - Platform (m²)0.69x0.93
Ground Clearance (m)0.016
Height - Drive (m)3.66
Height - Elevated Platform (m)3.66
Height - Guardrail (m)1.1
Height - Lowered Platform (m)0.46
Height - Stowed (m)1.78
Height - Working (m)5.5
Length - Platform (m)0.93
Length - Stowed (m)1.4
Size - Tyre30x10.2
Turning Radius - Inside (m)0
Turning Radius - Outside (m)1.4
Wheelbase (m)1.07
Width - Platform (m)0.69
Length - Platform with Extensions (m)0.41
Height - Platform (Indoor) (m)3.65
Height - Platform (Outdoor) (m)3.65
Height - Toeboard (")6
Width - Platform with Extensions (m)0.69
Width - Working (m)0.78
Technical Specifications
Capacity - Hydraulic Tank (L)5.9
Capacity - Platform (kg)227
Gradeability (%)30
Load - Safe Working (kg)227
Load - Tyre (max) (kg)430
No. of Lifting Eyes4
No. of Persons (Max)2
Pressure - Floor (Occupied) (psf/kPa)8.1/169
Pressure - Per Tyre Contact (psi/kPa)275/86
Speed - Drive (Elevated) (mph)0.5
Speed - Drive (Lowered) (mph)3
Speed - Wind (max) (mph)28
Tyre TypeSolid Non Marking
Speed - Lower/Raise Function (s)12.1/15.2
Capacity - Platform Retracted (kg)227
Capacity - Platform w/o Extension (kg)227
Hydraulic SystemATF Dexron III
Capacity - Platform Only when Extended (kg)227
