Snorkel S4732E 32' Electric Scissor Lifts
The Snorkel S4732E is a robust and versatile scissor lift, perfect for construction tasks requiring elevated access. With its compact design and excellent manoeuvrability, it ensures safety and efficiency on site. Ideal for both indoor and outdoor use.
Item ID: 50000035
Reference: 075300
Basic Dimensions
Length (m)2.3
Width (m)1.19
Height (m)9.75
Weight (kg)2693
Environmental & Sustainability
Sound Power (dB)70
Convenience Features
All Motion AlarmYes
Non Marking TyresYes
Power To CageYes
Proportional ControlsYes
All-Wheel SteeringNo
Extended PlatformYes
Fold Down Hinged Railing SystemYes
Self Locking GateYes
OutriggersNo
Dual Flow HydraulicsNo
HourmeterYes
Lifting Check ValvesNo
Manual DescentYes
Oscillating Axle ChassisNo
Proportional Direct DC Electric DriveYes
Proportional Lift UpYes
Quad Holding BrakesNo
Single Pump HydraulicsNo
Slide-Out Engine TrayNo
Tilt SensorYes
Power Source
Power Source / Fuel TypeBatteryElectric
Battery (V/Ah)4x 6V / 240Ah
Voltage (V)24
Safety Information
Flashing BeaconYes
Harness RingsYes
HornYes
Tilt AlarmYes
Dual Holding BrakesYes
Emergency Stop ButtonYes
Overload Sensing SystemYes
Technical Dimensions
Area - Platform (m²)2.3326
Ground Clearance (m)0.19
Ground Clearance - Stowed (mm)0.19
Height - Drive (m)9.75
Height - Guardrail (m)1.10
Height - Working (m)11.8
Length - Platform (m)2.14
Outreach - Horizontal (m)0
Size - Tyre381 x 127
Turning Radius - Inside (m)0.25
Turning Radius - Outside (m)2.41
Wheelbase (m)1.77
Width - Platform (m)1.09
Height - Platform (m)9.75
Height - Working (max) (m)11.8
Deck Extension (m)1.21
Technical Specifications
Capacity - Hydraulic Tank (L)17
Gradeability (%)25
Load - Safe Working (kg)350
No. of Lifting Eyes4
No. of Persons (Max)2
Slope (Max) (%)25
Speed - Drive (Elevated) (mph)0.4
Speed - Drive (Lowered) (mph)2
Speed - Falling (Loaded) (s)58
Speed - Rising (Loaded) (s)50
Speed - Wind (max) (mph)28
Tyre TypeNon Marking Solid Rubber
Charger Type90-240 / 25
Drive Type2‑wheel drive
Output - Power24V DC
Capacity - Distributed (Main Platform) (kg)350
Capacity - Total (kg)350
Weight - Total Aerial Platform (max) (kg)2693
