Skyjack SJ6832 RTE 32' Electric Scissor Lift
The Skyjack SJ6832 is a robust electric scissor lift designed for indoor use, offering excellent reach and stability. With compact dimensions, it’s ideal for tight spaces in construction projects, ensuring efficiency and safety. Elevate your worksite productivity with this reliable lift.
Item ID: 50000032
Reference: 075007
Basic Dimensions
Length (m)2.72
Width (m)1.76
Height (m)2.51
Weight (kg)3780
Environmental & Sustainability
Sound Power (dB)76
Convenience Features
All Motion AlarmYes
Non Marking TyresYes
Power To CageYes
Proportional ControlsNo
All-Wheel SteeringNo
Extended PlatformYes
Fold Down Hinged Railing SystemYes
Self Locking GateYes
OutriggersYes
Dual Flow HydraulicsNo
HourmeterYes
Lifting Check ValvesNo
Manual DescentYes
Oscillating Axle ChassisNo
Proportional Direct DC Electric DriveNo
Proportional Lift UpNo
Quad Holding BrakesNo
Slide-Out Engine TrayNo
Tilt SensorYes
Power Source
Power Source / Fuel TypeElectric
Battery (V/Ah)48V / 330Ah
Voltage (V)48
Safety Information
Flashing BeaconYes
Harness RingsYes
HornYes
Tilt AlarmYes
Vibration Level (m/s2)0.5
Dual Holding BrakesYes
Emergency Stop ButtonYes
Overload Sensing SystemYes
Technical Dimensions
Area - Platform (m²)3.4648
Ground Clearance (m)0.20
Ground Clearance - Stowed (mm)200
Height - Closed (m)1.81
Height - Drive (m)9.75
Height - Guardrail (m)1.1
Height - Stowed (m)2.51
Height - Working (m)11.75
Length - Platform (m)2.44
Length - Stowed (m)2.72
Size - Tyre26 x 12
Turning Radius - Inside (m)1.52
Turning Radius - Outside (m)3.96
Wheelbase (m)2.04
Width - Platform (m)1.42
Height - Hand Rails Down (m)1.75
Height - Platform (m)9.75
Height - Working (max) (m)11.75
Deck Extension (m)1.52
Width - Working (mm)1.76
Technical Specifications
Capacity - Hydraulic Tank (L)87
Gradeability (%)38
Load - Safe Working (kg)454
Load - Wheel (max) (kg)1860
No. of Lifting Eyes2.51
No. of Persons (Max)4
Pressure - Per Tyre Contact (psi/kPa)1248
Slope (Max) (%)45
Speed - Drive (Elevated) (mph)0.4
Speed - Drive (Lowered) (mph)3.8
Speed - Drive (Raised) (mph)0.4
Speed - Drive (Stowed) (mph)3.5
Speed - Falling (Loaded) (s)36
Speed - Rising (Loaded) (s)39
Speed - Wind (max) (mph)28
Tyre TypeFoam Filled Non Marking
Charger TypeOnboard generator: The SJ6832 RTE has an on-board generator that can charge the batteries while the machine is still in use
Drive TypeFour Wheel Drive
Speed - Lower/Raise Function (s)Raise Time: 43–55 seconds Lower Time: 40–50 seconds
Output - Power24.8hp (18.5 kW)
Capacity - Distributed (Extension Deck) (kg)300
Capacity - Distributed (Main Platform) (kg)700
Capacity - Total (kg)454
Weight - Total Aerial Platform (max) (kg)3577
