Skyjack SJ8841 RT 40' Diesel Scissor Lift
The Skyjack SJ8841 RT is a robust rough terrain scissor lift designed for outdoor construction projects. With impressive lifting capabilities and exceptional stability, this machine ensures efficient operation on uneven surfaces. Its compact dimensions allow for easy manoeuvrability, making it an essential tool for any construction site.
Item ID: 50000066
Reference: 078064
Basic Dimensions
Length (m)3.7
Width (m)2.2
Height (m)2.9
Weight (kg)4935-6173
Environmental & Sustainability
Sound Power (dB)67
Average Usage Emissions Per Operating Hour (ERA)9.7
Average Consumption Per Operating Hour (ERA)3.1
Average Engine Operating Hours Over A Rental Day (ERA)2.1
Convenience Features
All Motion AlarmYes
Non Marking TyresYes
Power To CageYes
Proportional ControlsYes
Extended PlatformYes
Fold Down Hinged Railing SystemYes
Self Locking GateYes
OutriggersYes
Proportional Direct DC Electric DriveYes
Quad Holding BrakesNo
Power Source
Power Source / Fuel TypeDiesel
EngineDiesel Kubota D1305 21.7 (kW) 3000 rpm
Engine MakeKubota
Engine ModelD1305
Safety Information
Flashing BeaconYes
Harness RingsYes
HornYes
Tilt AlarmYes
Dual Holding BrakesYes
Emergency Stop ButtonYes
Technical Dimensions
Area - Platform (m²)6.29
Ground Clearance (m)0.20
Ground Clearance - Stowed (mm)200
Height - Drive (m)12.5
Height - Guardrail (m)1.1
Height - Stowed (m)2.9
Height - Working (m)14.5
Length - Platform (m)3.7
Size - Tyre10 x 16.5
Turning Radius - Inside (m)4.01
Turning Radius - Outside (m)6.30
Wheelbase (m)2.27
Width - Platform (m)1.7
Height - Hand Rails Down (m)2.2
Height - Platform (m)12.192
Height - Working (max) (m)14.5
Deck Extension (m)1.22
Technical Specifications
Capacity - Fuel Tank (L)49.21
Capacity - Hydraulic Tank (L)75
Gradeability (%)30
Load - Safe Working (kg)681
Load - Wheel (max) (kg)2858
No. of Lifting Eyes4
No. of Persons (Max)5
Speed - Drive (Elevated) (mph)0.21
Speed - Drive (Lowered) (mph)2.6
Speed - Drive (Raised) (mph)0.21
Speed - Drive (Stowed) (mph)2.6
Speed - Falling (Loaded) (s)53
Speed - Rising (Loaded) (s)56
Speed - Wind (max) (mph)28
Tyre TypeAir Filled
Drive Type4WD
Output - Power21.7kW (29.1hp)
Capacity - Distributed (Extension Deck) (kg)227
Capacity - Distributed (Main Platform) (kg)454
Capacity - Total (kg)681
