JLG E450AJ 45' Electric Articulated Boom Lift Earth Bonded
The JLG E450AJ is a versatile articulated boom lift, ideal for reaching heights with ease and precision. Its compact design and outstanding manoeuvrability make it suitable for tight job sites, ensuring efficient operation in construction tasks. Enhance your productivity with this reliable lift solution.
Item ID: 50000093
Reference: 076361
Basic Dimensions
Length (m)6.45
Width (m)1.75
Height (m)2
Weight (kg)6531.73
Convenience Features
All Motion AlarmYes
Descent & Travel AlarmYes
Non Marking TyresYes
Power To CageYes
Power Source
Power Source / Fuel TypeElectric
Battery (V/Ah)8 x 6V/370Ah
Engine - Stage 3ANo
Engine - Stage 3B Tier 4No
Engine - Stage 5No
Voltage (V)48
Safety Information
Harness RingsYes
HornYes
Tilt AlarmYes
Technical Dimensions
Area - Platform (m²)1.16
Ground Clearance (m)0.2
Height - Closed (m)2
Height - Guardrail (m)1.1
Height - Lowered Platform (m)1.22
Height - Stowed (m)2
Height - Up & Over (m)7.7
Height - Working (m)15.54
Length - Platform (m)1.52
Length - Stowed (m)6.45
Outreach - Horizontal (m)7.24
Tail Swing (m)0
Turning Radius - Outside (m)3.15
Wheelbase (m)2.01
Width - Platform (m)0.76
Technical Specifications
Capacity - Hydraulic Tank (L)15.14
Capacity - Lift (kg)227
Capacity - Platform (kg)227
Capacity - Platform Unrestricted (kg)226.8
Fly Boom Arc (°)141
Gradeability (%)30
Inclination - Allowable (max) (°)3
Load - Safe Working (kg)227
Load - Wheel (max) (kg)3130
No. of Lifting Eyes4
No. of Persons (Max)2
Pressure - Per Tyre Contact (psi/kPa)110
Range - Articulated Jib (°)141
Rotation - Cage (°)180
Rotation - Horizontal Jib (°)0
Rotation - Hydraulic Platform (°)180
Rotation - Turntable (°)360
Rotation - Turret (°)360
Rotation - Jib (°)141
Speed - Drive (Elevated) (mph)0.5
Speed - Drive (Lowered) (mph)4.5
Speed - Wind (max) (mph)28
Swing Non Continuous (°)360
Tyre TypeFoam Filled
