Manitou 100VJR 32' Electric Vertical Mast Boom Lift
The Manitou 100VJR is a versatile and compact machine, perfect for tight spaces. With its impressive lifting capabilities and manoeuvrability, it's ideal for various construction tasks. Enhance your project efficiency with this reliable equipment.
Item ID: 50000181
Reference: 080105
Basic Dimensions
Length (m)2.82
Width (m)0.998
Weight (kg)2650
Convenience Features
All Motion AlarmYes
Articulating JibYes
Descent & Travel AlarmYes
Non Marking TyresYes
Platform Load Sense SystemYes
Proportional ControlsYes
Dual Wheel BrakesYes
Hydraulic Brake ReleaseYes
On Board Diagnostic SystemYes
2WD Electric DriveYes
Extended Reach And Up-&-Over HeightYes
Low Charge Function Cut-OutYes
Manual Descent SystemYes
Powered Platform/Basket RotationYes
Strobe LightYes
Versatile Articulating JibYes
Power Source
Power Source / Fuel TypeElectric
Battery TypeOther
Voltage (V)24
Battery (V/Ah)24 / 250
Safety Information
Harness RingsYes
HornYes
Operating Temperature-20 to +45
Tilt AlarmYes
Vibration Level (m/s2)0.5
Technical Dimensions
Ground Clearance (m)0.1
Height - Closed (m)1.99
Height - Drive (m)6.67
Height - Guardrail (m)1.1
Height - Stowed (m)1.99
Outreach - Horizontal (m)3.15
Outreach - Working (m)3.15
Size - Tyre16x5x11
Turning Radius - Inside (m)0.49
Turning Radius - Outside (m)1.98
Wheelbase (m)1.2
Width - Platform (m)0.90
Height - Platform (max) (m)7.9
Height - Working (max) (m)9.9
Length - Platform (max) (m)0.75
Width - Frame (m)0.99
Technical Specifications
Capacity - Hydraulic Tank (L)22
Capacity - Lift (kg)200
Controls24
Gradeability (%)25
Load - Safe Working (kg)200
Load - Tyre (max) (kg)1490
No. of Lifting Eyes2
No. of Persons (Max)2
Range - Articulated Jib (°)140
Rotation - Horizontal Jib (°)350
Speed - Drive (Elevated) (mph)0.4
Speed - Drive (Lowered) (mph)2.78
Speed - Wind (max) (mph)28
Tyre TypeSolid Non Marking
Capacity (max) (kg)200
Motor TypePump Motor: 2.2/24
