Wacker Neuson CRT48-35L 1200mm Diesel Ride-On Power Float
The Wacker Neuson CRT48-35L 1200mm is engineered for superior finishing of large concrete surfaces. Its powerful diesel engine provides exceptional performance, while the ride-on design enhances operator comfort and efficiency. Ideal for contractors seeking to achieve a smooth, professional finish on their projects.
Item ID: 50004099
Reference: 010050
Basic Dimensions
Length (mm)2566
Height (mm)1473
Width (mm)1295
Weight (kg)603
Environmental & Sustainability
Emission LevelLevel V
Convenience Features
Features
- Optimum manoeuvrability due to its balanced power-to-weight ratio.
- Sensitive, ergonomically designed twin-lever controls reduce amount of force needed to control the unit but still provides feedback from concrete conditions for better floating and high production finishing jobs.
- A unique variable clutch offers proper torque and speed range to match concrete conditions without mechanical adjustments.
- Good visibility from the front and rear lights as standard – especially on dim lit and night operations.
Power Source
Power Source / Fuel TypeDiesel
Engine TypeWater-cooled 4-cylinder aspirated diesel engine
Engine MakeKohler
Engine ModelKDW1404
Safety Information
Sound Power (dB)110.2
Sound Pressure (dB)91.1
Vibration Level (m/s2)1.37
Safety SwitchYes
Technical Dimensions
Bore & Stroke (mm)75 x 77.6
Dimensions - Engine LxWxH (mm)599 x 412 x 519
Diameter - Trowelling (mm)1200
Technical Specifications
Cylinder Sleeve Type4 cylinders in line
Displacement1372
Compression22.8:1
Power - Net17.9 (24)@2700RPM
Power - Continuous Rated24.5 (33.3) @3600
Torque - Net (Nm)70 (51.6)@1600RPM
Capacity - Engine Oil (L)3.3
Weight - Engine Dry (kg)98
Cooling TypeFan
Oil TypeSAE 10W40
No. of Blades10
MovementRide-On
Speed - Trowelling (rpm)25-165
Area - Trowelling (m2)2.8-3.0
Capacity - Gearbox Oil (L)1.83
Time - Operating (mins)240
Pitch (°)0-25
Clutch TypeVariable Speed
