JCB S1930E 19' Electric Scissor Lift Earth Bonded
Basic Dimensions
Length (m)1.78
Width (m)0.76
Height (m)2.11
Weight (kg)1526
Environmental & Sustainability
Sound Power (dB)66.7
Convenience Features
All Motion AlarmYes
Non Marking TyresYes
Power To CageYes
Proportional ControlsYes
All-Wheel SteeringNo
Extended PlatformYes
Fold Down Hinged Railing SystemYes
Self Locking GateYes
OutriggersNo
Dual Flow HydraulicsNo
HourmeterYes
Lifting Check ValvesYes
Manual DescentYes
Oscillating Axle ChassisNo
Proportional Direct DC Electric DriveYes
Proportional Lift UpYes
Quad Holding BrakesNo
Single Pump HydraulicsYes
Slide-Out Engine TrayYes
Tilt SensorYes
Power Source
Power Source / Fuel TypeBatteryElectric
Battery (V/Ah)4x 6V / 225Ah
Voltage (V)25
Amps (A)25
Safety Information
Flashing BeaconYes
Harness RingsYes
HornYes
Tilt AlarmYes
Dual Holding BrakesYes
Emergency Stop ButtonYes
Overload Sensing SystemYes
Technical Dimensions
Area - Platform (m²)1.2464
Ground Clearance (m)0.07
Ground Clearance - Stowed (mm)0.7
Height - Drive (m)5.79
Height - Stowed (m)2.11
Height - Working (m)7.8
Length - Platform (m)1.64
Size - Tyre30.5 x 11.5
Turning Radius - Inside (m)0.04
Turning Radius - Outside (m)1.49
Wheelbase (m)1.33
Width - Platform (m)0.76
Height - Hand Rails Down (m)1.86
Height - Platform (m)5.79
Height - Working (max) (m)7.8
Deck Extension (m)0.9
Technical Specifications
Capacity - Hydraulic Tank (L)18
Charging Time8–10 hours
Gradeability (%)25
Load - Safe Working (kg)230
Load - Wheel (max) (kg)380
No. of Lifting Eyes2.11
No. of Persons (Max)2
Slope (Max) (%)3
Speed - Drive (Elevated) (mph)0.5
Speed - Drive (Lowered) (mph)2
Speed - Falling (Loaded) (s)25-30
Speed - Rising (Loaded) (s)20-25
Speed - Wind (max) (mph)28
Tyre TypeSolid Non Marking
Charger Type100–240V AC input / 25A output
Drive TypeFront‑wheel drive, rear‑wheel steer
Output - Power4.5 hp DC electric motor
Hydraulic SystemSingle‑pump hydraulic lift system
Capacity - Distributed (Extension Deck) (kg)120
Capacity - Distributed (Main Platform) (kg)230
Capacity - Total (kg)230
Weight - Total Aerial Platform (max) (kg)1526
