Genie Z-34/22 IC 34' Diesel Articulating Boom Lift Earth Bonded
The Genie Z-34/22 IC EBOND is a robust, versatile aerial work platform designed for enhanced mobility and superior reach. Its compact dimensions enable easy navigation in tight spaces, making it ideal for construction and maintenance tasks. Experience reliable performance and efficiency on site.
Item ID: 50000116
Reference: 079013
Basic Dimensions
Length (m)4.11
Width (m)1.85
Height (m)2.29
Weight (kg)4994
Environmental & Sustainability
Sound Power (dB)80
Average Usage Emissions Per Operating Hour (ERA)10.6
Average Consumption Per Operating Hour (ERA)3.4
Average Engine Operating Hours Over A Rental Day (ERA)2.3
Average Usage Emissions Per Operating Hour (ERA)10.6
Average Consumption Per Operating Hour (ERA)3.4
Average Engine Operating Hours Over A Rental Day (ERA)2.3
Convenience Features
All Motion AlarmYes
4WDYes
Non Marking TyresYes
Platform Load Sense SystemYes
Platform WorklightsYes
Proportional ControlsYes
Self Levelling PlatformYes
Power Source
Power Source / Fuel TypeDiesel
Engine24.8 hp 18.5 kW Kubota D1105 Diesel T4i/T4f Stage IIIA/V CN III GM .998L G/LPG 29.6 hp
Voltage (V)12
Engine MakeKubota
Engine ModelD1105
Safety Information
Flashing BeaconYes
Harness RingsYes
HornYes
Tilt AlarmYes
Vibration Level (m/s2)2.5
Technical Dimensions
Area - Platform (m²)1.08
Ground Clearance (m)0.17
Height - Elevated Platform (m)10.54
Height - Stowed (m)2.06
Height - Up & Over (m)4.6
Height - Working (m)12.54
Length - Cage (m)1.42
Length - Jib (Overall) (m)1.22
Length - Platform (m)1.42
Length - Stowed (m)5.66
Outreach - Horizontal (m)6.78
Size - Tyre25 x 42
Turning Radius - Inside (m)1.8
Turning Radius - Outside (m)4.11
Wheelbase (m)1.88
Width - Platform (m)0.76
Technical Specifications
Capacity - Fuel Tank (L)35.2
Capacity - Hydraulic Tank (L)71.9
Capacity - Platform (kg)227
Capacity - Platform Unrestricted (kg)227
Gradeability (%)45
Load - Safe Working (kg)227
No. of Persons (Max)2
Pressure - Floor (Occupied) (psf/kPa)221 / 10.58
Pressure - Ground Bearing (max) (kg/cm2)3.16
Pressure - Hydraulic (bar)221
Pressure - Per Tyre Contact (psi/kPa)45 / 310
Rotation - Hydraulic Platform (°)180
Rotation - Turntable (°)355
Rotation - Jib (°)139
Speed - 2WD (mph)3
Speed - 4WD (mph)3
Speed - Drive (Elevated) (mph)0.68
Speed - Drive (Lowered) (mph)3
Speed - Wind (max) (mph)28
Tyre TypeSolid Non Marking
