SupaRule 600E Cable Height Meter
The SupaRule 600E is an essential tool for precise measurements in construction projects. Its robust design and clear markings ensure accuracy and durability, making it ideal for both professionals and DIY enthusiasts. With its user-friendly features, this measuring rule is a must-have for any toolkit.
Item ID: 50001050
Reference: 177004
Basic Dimensions
Weight (kg)0.5
Height (mm)205
Length (mm)100
Width (mm)70
Convenience Features
Features
- Quick measurement – saves time and money
- Inherently safe – No physical connection to cables or wires required to obtain measurement
- Extremely accurate – measures to accuracy of 0.5%
- Easy-to-Use – Simple, three-button operation ensures fast, effective measurements with a minimum of operator training
- Compact size – It’s lightweight and handheld. Portability allows easy transport and multiple measurements
- Maintenance Free – proven reliability in the field, no adjustments required
Addition/SubtractionNo
Area/VolumeNo
Bluetooth SMARTNo
CalculatorNo
Camera FunctionNo
CompassNo
Continuous MeasurementNo
Distance MeasurementNo
DXF Data CaptureNo
Gallery with USB DownloadNo
Height Profile MeasurementsNo
Height TrackingNo
Illuminated DisplayNo
Inclination TrackingNo
Long Range ModeNo
Measure with the PictureNo
Min/Max. MeasurementNo
Painter FunctionNo
Personalized FavouritesNo
Pointfinder with 4x ZoomNo
Point-to-Point MesurementsNo
Slope Object MeasurementNo
Smart Angle MeasurementNo
Smart Area MeasurementNo
Smart Horizontal ModeNo
Stake Out FunctionNo
Tilt MeasurementNo
Touch ScreenNo
TrapeziumNo
WLAN Data TransmissionNo
Power Source
Power Source / Fuel TypeBattery
Battery Life50,000 mesurements
Battery TypeAlkaline
Safety Information
Temperature - Operating (°C)-10 to +40
Technical Dimensions
Range - Operating (m)3 - 23 max.
Width - Beam at Distance (m)0.6 (@ 10m) / 0.7 (@ 12m) / 0.9 (@ 15m) / 1.4 (@ 23m)
Width - Gap Between Wires (min) (mm)150
Technical Specifications
Accuracy0.5% ± 2 digits
Purpose/Made for
- Telephone lines
- Distribution lines
- Transmission lines
- Cable television
- Street lighting
- SAG (lowest point to ground)
- Clearances on construction sites
Resolution
- Range: less than 10m: 5mm
- Range: more than 10m: 10mm
Measurement UnitsImperial (feet / inches) or Metric (meters)
No. Wires Measured6
Time - Auto Power off Delay (min)3
