JCB 1THT 1t Diesel 4WD High Tip Site Dumper Stage 3A
The JCB 1THT Stage 3A is a compact and efficient dumper, ideal for construction projects requiring precision and power in confined spaces. Its robust design ensures reliability, while its compact size allows for easy manoeuvrability.
Item ID: 50002847
Reference: 015150
Basic Dimensions
Length (mm)2980
Height (mm)2830
Width (mm)1120
Weight (kg)1310
Environmental & Sustainability
Average Usage Emissions Per Operating Hour (ERA)11.4
Average Consumption Per Operating Hour (ERA)3.6
Average Engine Operating Hours Over A Rental Day (ERA)2.5
Convenience Features
Load SensingYes
TelematicsYes
Sunbelt Paint/Decals/Hi Viz RaYes
Power Source
Power Source / Fuel TypeDiesel
Battery (V/Ah)12V / 74Ah
Voltage - System (V)12
Output - Alternator (Ah)30
Engine MakeKubota
Engine ModelD905
Engine Stage/TierStage3A
Power - Engine (max) (kW)15.5
Power - I.C. Engine Rating (hp)20.8
Safety Information
Service BrakeYes
Parking BrakeYes
Vibration - Whole Body (m/s2)0.529
Vibration - Hand-Arm (m/s2)2.5
Noise Level (dB)29
SeatbeltYes
RollbarYes
Folding ROPS FrameYes
Enclosure CabNo
Standard Steps & HandlesYes
Technical Dimensions
Ground Clearance (mm)240
Wheelbase (m)1.44
Width - Over Tyres (mm)0.99 / 1.12 (*When fitted with narrow tyres)
Bore & Stroke (mm)10.5 –21.5 mm
Size - Tyres255 / 75 x 15.2 x 8 ply (option 7.0 x 12 narrow tyre)
Radius - Turning (Range) (m)2.3 - 5.43
Height - Tip (m)1.62
Height - To Skip Front Lip (Untipped) (m)1.17 (With high tip mechanism raised 2.26)
Height - To Skip Front Lip (Tipped) (m)1.62
Distance - Front Discharge (m)0.39
Height - To Top of ROPS (With/w/o Beacon) (mm)2570 - 2790
Height - ROPS Folded (mm)1720
Width - Track (Standard/Narrow Tyres) (mm)0.85
Length - ROPS (mm)0.31
Technical Specifications
Steering & Traction DriveOrbitrol hydrostatic steering unit powering central hydraulic steering ram
Transmission TypeHyrdostatic Pump to hydraulic wheel motors
Capacity - Fuel Tank (L)35
Capacity - Hydraulic Tank (L)25
Torque (Nm @ rpm)56 @ 2600
No. of Cylinders3
Displacement (L)0.898
Fuel Injection Pumpdirect fuel injection system controlled with a mechanically actuated fuel injection pump
Gradeability (%)20
Brakes TypeHydrostatic dynamic braking on rear wheel motors
Speed - Travel (Range) (mph)7.4
Pressure - Working (bar)152
Drive Control TypeHydrostatic 1/1
Flow Rate - Pump (l/min)29
Payload (t)1
Angle - Skip Tip (°)90
Weight - Operating (ROPS - Full Tank & 75kg Operator) (kg)1400
Tipping TypeFront Tip - High Tip - Swivel Tip
Angle - Steering (°)45
Oscillation (°)14
Capacity - Skip (Struck) (L)450
Capacity - Skip (Heaped) (L)540
Capacity - Skip (Liquid) (L)320
Angle - Swivel Dump (°)90
AspirationNaturally Aspirated
Rotation - DirectionCounter-clockwise (viewed from the flywheel side)
