JCB 3TFT 3t Diesel 4WD Front Tip Site Dumper Stage 3A
The JCB 3TFT Stage 3A is a versatile compact tractor ideal for construction tasks. Its robust design and powerful performance ensure efficiency on-site, making it a reliable choice for contractors. Experience exceptional manoeuvrability and productivity with this trusted machine.
Item ID: 50002826
Reference: 015055
Basic Dimensions
Length (mm)3730
Height (mm)1470
Width (mm)1940
Weight (kg)2345
Environmental & Sustainability
Average Usage Emissions Per Operating Hour (ERA)17
Average Consumption Per Operating Hour (ERA)5.4
Average Engine Operating Hours Over A Rental Day (ERA)3.2
Convenience Features
Load SensingYes
TelematicsYes
Sunbelt Paint/Decals/Hi Viz RaYes
Power Source
Power Source / Fuel TypeDiesel
Battery (V/Ah)12V / 74Ah
Voltage - System (V)12
Output - Alternator (Ah)55
Engine MakeKubota
Engine ModelV2203M
Engine Stage/TierStage3A
Power - Engine (max) (kW)32.4
Power - I.C. Engine Rating (hp)43.5
Safety Information
Service BrakeYes
Parking BrakeYes
Vibration - Whole Body (m/s2)0.529
Vibration - Hand-Arm (m/s2)<2.5
Noise Level (dB)101
Sound Pressure (dB)86.1
SeatbeltYes
RollbarYes
Folding ROPS FrameYes
Standard Steps & HandlesYes
Technical Dimensions
Ground Clearance (mm)280
Wheelbase (m)1.95
Size - Tyres295 / 80 x 15.3 (10 ply)
Radius - Turning (Range) (m)4.71
Height - Tip (m)1.5
Height - ROPS Tilted (mm)1860
Height - Skip (m)0.79
Height - ROPS (mm)2920
Width - Skip (mm)1690
Length - ROPS (mm)4190
Technical Specifications
Steering & Traction DriveOrbital Hydrostatic Steering unit powering central hydraulic steering ram
Loads - Axle (kg)75 (Rear)
Capacity - Fuel Tank (L)37
Capacity - Hydraulic Tank (L)37
Torque (Nm @ rpm)147
No. of Cylinders4
Gradeability (%)25
Cooling SystemBASF Glysatin G48/water mixture 50% Extended life antifreeze
Brakes TypeMulti Plate in board oil immersed dics on front axle / Over centre handbrake oil immersed discs on front axle
Speed - Travel (Range) (mph)11.8
Pressure - Working (bar)172
Drive Control TypeManual - 3 Forward / 1 Reverse / Manual Gearbox
Flow Rate - Pump (l/min)30
Payload (t)3
Tipping TypeNo Swivel Front Tip
Angle - Steering (°)30
Articulation (°)30
Oscillation (°)10.5
Capacity - Skip (Struck) (L)1600
Capacity - Skip (Heaped) (L)1950
Capacity - Skip (Liquid) (L)1250
AspirationNaturally Aspirated
Capacity - Cooling Tank (L)9
