JCB 3TSTM 3t Diesel Swivel Tip Site Dumper Stage 3A
The JCB 3TSTM Stage 3A is a robust and versatile compact dumper, perfect for various construction tasks. Its compact dimensions ensure excellent manoeuvrability on tight sites, while delivering impressive power and performance. Ideal for both professional contractors and DIY enthusiasts alike.
Item ID: 50002831
Reference: 015060
Basic Dimensions
Length (mm)3950
Height (mm)1470
Width (mm)1690
Weight (kg)2290
Environmental & Sustainability
Average Usage Emissions Per Operating Hour (ERA)17
Average Consumption Per Operating Hour (ERA)5.4
Average Engine Operating Hours Over A Rental Day (ERA)3.2
Convenience Features
Load SensingYes
TelematicsYes
Sunbelt Paint/Decals/Hi Viz RaYes
Power Source
Power Source / Fuel TypeDiesel
Battery (V/Ah)12V / 74Ah
Voltage - System (V)12
Output - Alternator (Ah)55
Engine MakeKubota
Engine ModelV2203M
Engine Stage/TierStage3A
Power - Engine (max) (kW)32.4
Power - I.C. Engine Rating (hp)43.5
Safety Information
Service BrakeYes
Parking BrakeYes
Noise Level (dB)101
Sound Pressure (dB)84
SeatbeltYes
RollbarYes
Folding ROPS FrameYes
Standard Steps & HandlesYes
Technical Dimensions
Ground Clearance (mm)280
Wheelbase (m)1.94
Width - Over Tyres (mm)1960
Bore & Stroke (mm)87 x 92.4
Size - Tyres11.5 / 80 x 15.3 (14 ply)
Height - Loadover (m)1.57
Radius - Turning (Range) (m)4.46 - 4.58
Height - To Skip Front Lip (Untipped) (m)1.45
Height - To Skip Front Lip (Tipped) (m)0.76
Height - Over Skip (Tipped) (m)2.86
Distance - Front Discharge (m)0.55
Distance - Side Discharge (m)0.32
Diameter - Turning Circle (m)9.1
Height - To Top of ROPS (With/w/o Beacon) (mm)3020
Height - ROPS Folded (mm)1.86
Height - ROPS (mm)2690
Width - Skip (mm)1650
Width - Track (Standard/Narrow Tyres) (mm)1360
Technical Specifications
Transmission TypeHydrostatic
Capacity - Fuel Tank (L)37
Capacity - Hydraulic Tank (L)37
Torque (Nm @ rpm)147
No. of Cylinders4
Gradeability (%)25
Cooling SystemBASF Glysatin G48/water mixture 50% Extended life antifreeze
Brakes TypeMulti-plate in-board oil immersed discs on front axle - Foot brake-oil immersed discs on front/rear / Over centre parking brake-dry disc on gearbox
Speed - Travel (Range) (mph)11.8
Pressure - Working (bar)210
Drive Control Type
Manual – 3 Forward / 1
Reverse
Flow Rate - Pump (l/min)30
Payload (t)3
Angle - Skip Tip (°)90
Weight - Operating (ROPS - Full Tank & 75kg Operator) (kg)2390
Tipping TypeSwivel tip
Angle - Steering (°)30
Oscillation (°)10.5
Capacity - Skip (Struck) (L)1500
Capacity - Skip (Heaped) (L)1870
Capacity - Skip (Liquid) (L)1000
AspirationNaturally Aspirated
Capacity - Cooling Tank (L)9
