NiftyLift HR17N 56' Hybrid Articulated Boom Lift
The Niftylift HR17N is a robust and versatile access platform, designed for ease of use and exceptional reach. Ideal for construction and maintenance tasks, it offers impressive lifting capabilities within a compact footprint. Enhance your project efficiency with this reliable machine.
Item ID: 50000103
Reference: 079251
Basic Dimensions
Length (m)4.93
Width (m)1.5
Height (m)1.99
Weight (kg)7772
Environmental & Sustainability
Sound Power (dB)104
Average Usage Emissions Per Operating Hour (ERA)10.6
Average Consumption Per Operating Hour (ERA)3.4
Average Engine Operating Hours Over A Rental Day (ERA)2.7
Engine Stage/TierStageV
Average Usage Emissions Per Operating Hour (ERA)10.6
Average Consumption Per Operating Hour (ERA)3.4
Average Engine Operating Hours Over A Rental Day (ERA)2.7
Convenience Features
All Motion AlarmYes
Articulating JibYes
4WDNo
Automatic Battery Charger in Hybrid ModeYes
Electric Only CapabilityYes
Non Marking TyresYes
Platform Load Sense SystemYes
Power To CageYes
Proportional ControlsYes
Power Source
Power Source / Fuel TypeHybrid
Battery (V/Ah)8 x 6V/390Ah
EngineKubota D722. Battery Only Hybrid (Battery & Diesel)
Engine - Stage 3ANo
Engine - Stage 3B Tier 4No
Engine - Stage 5Yes
Voltage (V)48
Engine MakeKubota
Engine ModelD722
Safety Information
Flashing BeaconYes
Harness RingsYes
HornYes
Tilt AlarmYes
Technical Dimensions
Area - Platform (m²)1.2
Height - Elevated Platform (m)15
Height - Stowed (m)1.99
Height - Vertical Platform (max) (m)15
Height - Working (m)17
Length - Platform (m)1.5
Length - Stowed (m)4.93
Outreach - Horizontal (m)9.7
Outreach - Working (m)9.7
Size - Tyre70
Tail Swing (m)0.01
Turning Radius - Outside (m)3.5
Wheelbase (m)1.8
Width - Platform (m)0.8
Technical Specifications
Capacity - Fuel Tank (L)20
Capacity - Platform (kg)225
Capacity - Platform Unrestricted (kg)225
Gradeability (%)25
Load - Safe Working (kg)225
No. of Persons (Max)2
Pressure - Floor (Occupied) (psf/kPa)0.139
Pressure - Ground Bearing (max) (kg/cm2)14
Pressure - Hydraulic (bar)207
Rotation - Hydraulic Platform (°)430
Rotation - Jib (°)150
Speed - Drive (Lowered) (mph)2.2
Speed - Wind (max) (mph)28
Swing Non Continuous (°)430
Tyre TypeSolid
