Pressure - Working (max) (bar)16
Pressure - Burst (min) (bar)80
CEEN 1146:2005 / MED Shipswheel Approved
First Breath Activation (mbar)-20 to -30
Flow - Bypass (l/min)150 (nominal)
Flow - Peak Performance (l/min)>500
Materials - Air HoodPolyurethane coated viscose with clear PU visor
Materials - Carrying BagPVC Coated Nylon (AntiStatic – Polyurethane)
Materials - CylinderAluminium, Steel or Composite
Materials - Cylinder ValveAnodised Aluminium
Materials - Demand Valve CasingGlass filled Polyacetal and Polyamide
Materials - FacemaskNeoprene, Silicone or Procomp
Materials - Facemask VisorPolycarbonate
Materials - HP Pressure GaugeStainless Steel, Polycarbonate Lens
Materials - HP Pressure Gauge CoverNeoprene
Materials - MP Air Supply HoseChlorinated Polyethylene, fabric braid reinforcement,
Nitrile liner
Materials - MP Air Supply Hose FittingsNickel Plated Brass
Materials - O-RingsNitrile, Silicone, EPDM
Materials - Pressure Reducing ValveAnodised Aluminium
Materials - Reducing Valve SeatPolyamide (Nylon)
Materials - Reducing Valve SpringsStainless Steel
Materials - Rust TubeBrass
Materials - Strap BucklesPolyamide
Materials - Valve HandwheelGlass filled Polyamide
Pressure - 200 bar Inlet (bar)5.5-9.5
Pressure - 300 bar Inlet (bar)6-11
Pressure - Relief Valve (bar)13.5
Pressure - Static Positive (mbar)1-4
