JCB G200RS 200kVA Diesel Generator
Introducing the JCB G200RS, a robust and versatile generator designed for construction projects of all sizes. With its compact dimensions and powerful performance, this model excels in manoeuvrability and efficiency on site. Ideal for lifting and moving materials, the G200RS ensures reliability and productivity, making it a valuable addition to your equipment fleet. Experience the superior engineering and durability that JCB is renowned for.
Item ID: 50001277
Reference: 029630
Basic Dimensions
Length (cm)380
Width (cm)127
Height (cm)203.3
Weight (kg)350
Environmental & Sustainability
Emissions LevelStage IIIA
Consumption - Fuel (l/hr)50Hz: 48.50 | 60Hz: 51.10 (100% Standby)/ 50Hz: 46.20 | 60Hz: 47.80 (100% Prime)/ 50Hz: 37.30 | 60Hz: 38.00 (75% Prime)/ 50Hz: 25.40 | 60Hz: 26.40 (50% Prime)
Sound Pressure (dB)68
Average Usage Emissions Per Operating Hour (ERA)101.1
Average Consumption Per Operating Hour (ERA)32
Average Engine Operating Hours Over A Rental Day (ERA)5.5
Engine Stage/TierStage3A
Power Source
Power Source / Fuel TypeDiesel
Voltage - Options (V)230 / 400 (50Hz) | 277 / 480 (60Hz)
Phase3
Power - Prime (kVA/kW)200kVA / 160kW
Power - Standby (kVA/kW)50Hz: 220kVA 60Hz: 219kVA | 50Hz: 176kw60Hz: 175kW
Power - Factor (cos)0.8 (3-phase) / 1 (1-phase)
Capacity - Fuel Tank (L)515
EngineJohn Deere 6068HFU82
Battery (V/Ah)12V/ 850Ah
Battery TypeLeadAcid
Engine MakeJohnDeere
Engine Model6068HFU82
Safety Information
Insulation ClassH
Protection Class (IP)23
Temperature - Standby (max) (°C)600
Technical Dimensions
Bore & Stroke (mm)106 x 127
Diameter - Exhaust Pipe (mm)100
Technical Specifications
Horsepower (hp)227
Controller OptionsDSE 7320
Frequency50-60Hz
Alternator TypeUCI 274H
Autonomy15hrs @ 75% load (Prime)
No. of Cylinders6
Volume - Swept (L)6.8
Speed - Engine (rpm)1500-1800
AspirationTurbo Charged
Displacement (L)6.8
Displacement (cm³)6800
Capacity - Engine Oil (L)24.6
Ratio - Compression17.2 : 2
Injection TypeDirect
No. of Poles4
Exciter SystemSelf-regulating brushless
Coupling TypeFlexible disc
Bearing TypeSingle Bearing sealed
Coolant TypeWater (Engine) / Direct drive centrifugal blower fan (Alternator)
Capacity - Coolant (L)11.3
Temperature - Exhaust Gas (°C)600
Battery IsolatorStandard
ConnectionStar
GovernorElectronic
FilterPaper Element
Consumption - Engine Oil0.00001
Capacity - Oil (L)24.6
Flow - Exhaust Gas @ Standby (m3/min)30.12
Back Pressure - Allowed (max) (mbar)7.5
Voltage - Alternator RegulatorAVR +/- 1.0%
No. of Batteries1
Volume - Shipping (Sea Ready) (m3)9.8
Material - HousingGalvanised steel canopy
Capacity - Cubic (L)6.8
Recommended OilJCB EP 15W40
Output - RPR Rating (kW)169
Output - Standby Rating (kW)194
Speed ControlElectronic governor
Power - Net Rated (kWm)169
Size - Exhaust Discharge100
Capacity - Coolant HT (L)11.3
FinishTotal Protection +
Output - Power169kW (PRP) / 194kW (Standby)
