JCB G500RS 500kVA Diesel Generator
The JCB G500RS 500kVA generator is a robust and reliable power solution, ideal for construction sites and industrial applications. Designed for efficiency, this generator delivers a consistent power output, ensuring your operations run smoothly. Its compact dimensions make it easy to transport and manoeuvre on-site, while the durable construction ensures longevity in demanding environments. Experience the power and reliability of JCB with the G500RS generator, tailored to meet your energy needs.
Item ID: 50001280
Reference: 029655
Basic Dimensions
Length (cm)483.2
Width (cm)161.0
Height (cm)233.4
Weight (kg)680.0
Environmental & Sustainability
Emissions LevelStage IIIA
Consumption - Fuel (l/hr)50Hz: 113.50 | 60Hz: 135.10 (100% Standby)/ 50Hz: 102.40 | 60Hz: 120.30 (100% Prime)/ 50Hz: 79.50 | 60Hz: 88.00 (75% Prime)/ 50Hz: 54.80 | 60Hz: 61.00 (50% Prime)
Sound Pressure (dB)70
Average Usage Emissions Per Operating Hour (ERA)198.8
Average Consumption Per Operating Hour (ERA)62.9
Average Engine Operating Hours Over A Rental Day (ERA)6.2
Engine Stage/TierStage3A
Power Source
Power Source / Fuel TypeDiesel
Voltage - Options (V)230 / 400 (50Hz) | 277 / 480 (60Hz)
Phase3
Power - Prime (kVA/kW)500kVA / 400kW (50Hz)| 569kVA / 455kW (60Hz)
Power - Standby (kVA/kW)50Hz: 550kVA, 625kw| 60Hz: 440kVa, 500kW
Power - Factor (cos)0.8
Capacity - Fuel Tank (L)900
EngineVolvo TAD1651GE
Battery (V/Ah)24V/ 850Ah
Battery TypeLeadAcid
Engine MakeVolvo
Engine ModelTAD1651GE
Safety Information
Insulation ClassH
Protection Class (IP)23
Temperature - Standby (max) (°C)523
Technical Dimensions
Bore & Stroke (mm)144 x 165
Diameter - Exhaust Pipe (mm)200
Technical Specifications
Horsepower (hp)562
Controller OptionsDSE 7320 – Standard
Frequency50-60Hz
Alternator TypeSelf‑regulating brushless (HCI 544D)
Autonomy
14.8hrs @ 50% load (Prime)
10.2hrs @ 75% load (Prime)
7.5hrs @ 100% load (Prime)
No. of Cylinders6
Volume - Swept (L)16.12
Speed - Engine (rpm)1500-1800
AspirationTurbo Charged
Displacement (L)16.12
Displacement (cm³)16120
Capacity - Engine Oil (L)40
Ratio - Compression16.5 : 1
Injection TypeDirect
No. of Poles4
Exciter SystemSelf-regulating brushless
Coupling TypeFlexible disc
Bearing TypeSingle Bearing sealed
Coolant TypeWater (Engine) / Direct drive centrifugal blower fan (Alternator)
Capacity - Coolant (L)93
Temperature - Exhaust Gas (°C)523
Battery IsolatorStandard
ConnectionStar
Air Flow - Standby Intake (kg/hr)1919
Air Flow - Standby Cooling (m3/min)7.6
GovernorElectronic
FilterPaper Element
Consumption - Engine Oil0.00001
Capacity - Oil (L)40
Flow - Exhaust Gas @ Standby (m3/min)82.02
Back Pressure - Allowed (max) (mbar)8
Voltage - Alternator RegulatorAVR +/- 1.0%
No. of Batteries1
Volume - Shipping (Sea Ready) (m3)18.2
Material - HousingGalvanised steel canopy
Capacity - Cubic (L)16.12
Recommended OilJCB EP 15W40
Output - RPR Rating (kW)419
Output - Standby Rating (kW)462
Speed ControlElectronic governor
Size - Exhaust Discharge200
Capacity - Coolant HT (L)93
FinishTotal Protection +
Output - Power419kW (PRP) / 462kW (Standby)
Air Flow
7.6m3/min (Standby cooling)
1919kg/h (Standby intake)
