Clarke Champ 2.4L 2HP 7.6CFM 230V Electric Air Compressor
The Clarke Champ 2.4L electric air compressor is a powerful yet compact unit designed for efficiency in various construction tasks. With its reliable performance, it ensures consistent air supply for tools and equipment, making it an essential addition to any job site.
Item ID: 50004973
Reference: 002010
Basic Dimensions
Length (mm)510
Height (mm)400
Width (mm)270
Weight (kg)23.2
Convenience Features
FeaturesA tough, highly portable compressor for jobs in the hire and building trade. Handy for on-site tasks involving fixing, spraying, inflating and dust/debris blowing. Easy to carry, protective steel frame.
Oil FreeNo
TowableNo
WheelsNo
Power Source
Power Source / Fuel TypeElectric
Voltage (V)230
Frequency (Hz)50
Engine/Motor Power (hp/kW)2hp / 1.5kW
Safety Information
Temperature - Operating (℃)0 to +40
Sound Power (dB)96
Sound Pressure (dB)95
StandardsUKCA, CE
Technical Specifications
MaterialPowder‑coated steel frame, welded steel air receiver tank, aluminium pump body, steel/cast‑iron cylinder liner, aluminium cooling fins, steel motor housing, copper windings, aluminium motor end plates, steel fasteners, plastic shroud, plastic switch housing, rubber anti‑vibration feet, rubber hoses, brass fittings
Phase1
Displacement7.6 cfm (215L/min)
Power - Net1.5kW (2.0hp)
Starter TypeElectrical
Oil TypeClarke SAE40 compressor oil).
Plug Type13A (must be BS1363/A approved)
Fuse Type6.5A
DutyS1 (continuous)
Pressure (bar)10
Pressure - Tyre (bar/psi)0
Wheel TypeNo wheels or tyres
No. of Wheels2
FlywheelNo
Capacity - Air Receiver (L)2.4
