Vivax Metrotech vLoc3-Pro Receiver
The Vivax Metrotech vLoc3-Pro is a cutting-edge locator designed for precision in underground utility detection. Its compact design ensures ease of use, making it ideal for construction professionals. With advanced features, it delivers accurate results, enhancing project efficiency.
Item ID: 50001186
Reference: 183075
Basic Dimensions
Weight (kg)2.1
Height (mm)676
Length (mm)321
Width (mm)124
Convenience Features
RechargeableYes
Power Source
Power Source / Fuel TypeBattery
Battery Life
- Alkaline – typically 12 hours intermittent use at 70ºF (21ºC)
- Optional Lithium-ion – typically 27 hours intermittent use at 70ºF (21ºC)
Battery OptionsOptional rechargeable custom Lithium-ion batteries with 100-240V AC mains charger
Battery TypeAlkaline
Safety Information
Protection Class (IP)65
Temperature - Operating (°C)–20 to +50
Temperature - Storage (°C)–40 to +60
Technical Dimensions
Accuracy - Horizontal GPS (m)
- up to 9ft (3m) – +/- 3% of the depth
- over 9ft (3m) – +/- 5% of the depth
Range - Depth (max) (m)Dependent on the strength of the signal radiating to the locator
Technical Specifications
MaterialsHigh-impact thermoplastic (ABS) injection molded housing
Purpose/Made forLocating and pinpointing the position of buried pipes, cables, and sondes
RangevLoc Range
DisplayHigh-Visibility Colour Display, 4.3’ inch/10cm with 480 x 272 resolution
Time - Charging (hrs)6 hours
Accuracy - Depth/Measurement Precision (%)+/- 5% of the depth
Audio OutputBuilt-in loudspeaker
Capacity - Data Logging (months)
- 50 million record internal storage
- Data can also be transferred for storage, via cellular connectivity, into the cloud using the Vivax-Metrotech application, VMMAP
CleaningPower off. Soft, damp cloth.
DesignErgonomic, balanced and lightweight design for comfortable use
Dynamic Range (dB)25 dB
EnvironmentalIP65 and compliant with NEMA 4
External/Wired Connection
- Mini USB socket for software updates
- Accessory Socket – to charge the optional rechargeable batteries
- Bluetooth Port – to install optional Bluetooth module
External/Wireless ConnectionBluetooth, Wi-Fi
Gain Control
- Manual gain using + or - keys
- One-touch of + or - keys rescales to 60% of the bar graph scale
- In Vector Screen, + and – keys act as zoom feature to keep target utility in view
- In the Transverse Graph screen, the + key saves the screen graph, – key clears the screen
Mode Control
- Peak, Peak with arrows, Broad Peak
- Null, Delta Null
- Omni Directional Peak, Omni Directional Broad (The Intuitive setup menu enables the user to configure:
- Set up frequency selection to toggle by f pushbutton
- Setup location mode selection to toggle by m pushbutton
- Setup screen views selection to toggle by long press m pushbutton
- Units of measure (feet/meters)
- Sound (Pitch) – normal or modulated
- Language
- Continuous depth and current options
- Loudspeaker level
- Backlight
- Bluetooth pairing if installed
- Transmitter Radio Link if installed
- Warnings (Excessive Tilt, Overhead Signal, Shallow Cable, Signal Overload)
Power Button
- Power 50Hz and 60Hz
- Radio 10.0kHz - 22.7kHz bandwidth
- SD-USA: 256Hz/512Hz, SD-EUROPE: 320Hz/640Hz
Recommended Service Interval (months)12
Visual IndicationStatus Bar Information: - Antenna configuration: Peak, Peak with arrows, Broad Peak, Null, Delta Null, Omni Directional Peak, Omni Directional Broad - Line location - depth & current measurement - Battery condition - Speaker volume - Bluetooth and GNSS status (If installed) - Radio link to transmitter status (if installed) Locate screen (Classic display): - Signal strength - moving bar graph & numeric value - Bar graph color-coded indicating distortion level - Peak level indicator - Proportional left/right indication - Compass: full 360°-line direction indicator - Gain level (in dB) - Frequency selected - Configuration menus including GNSS status and data logging transfer status - Depth and current - Warnings (if activated) - Plug and play automatic recognition of accessories - Accessory specific custom screens Information screen: - GPS coordinates - Signal current and depth value - Log number Customer definable start-up screen
