JCB 19C -1E 1.5t Electric Tracked Mini Excavator
Introducing the JCB 19C-1E, a compact excavator designed for versatility and efficiency on construction sites. With its robust build and advanced features, this machine delivers exceptional performance in tight spaces. Ideal for various tasks, it ensures productivity and reliability. Experience the power of JCB engineering for your next project.
Item ID: 50002914
Reference: 021008
Basic Dimensions
Length (mm)3820 - 3860
Height (mm)2340
Width (mm)990
Weight (kg)1902
Convenience Features
SeatYes
ImmobiliserYes
Boom OffsetYes
Dozer BladeYes
Vinyl Static SeatYes
Track Lever PedalsYes
Full Control IsolationYes
LED WorklightsYes
On-Board ChargerYes
Retractable UndercarriageYes
Power Source
Power Source / Fuel TypeElectric
Battery TypeLithium
Voltage - System (V)48
Time - Charging (hrs)
On-board @ 110V – 10.5 hrs
On-board @ 230V – 5 hrs 20-80%, subject to environmental conditions.
Charging Cable Plug Type
Plug type 16A 110V (Yellow)
16A 230V (Blue)
16A 415V (Red)
Power - Engine (max) (kW)19.8
Power - I.C. Engine Rating (hp)26.6
Power - Motor (kW)7 - 20
Safety Information
Vibration - Whole Body (m/s2)0.41
Vibration - Hand-Arm (m/s2)2.5
Noise Level (dB)87
Sound Pressure (dB)68
Green Beacon Linked to SeatbeltYes
Travel AlarmYes
Boom WorklightYes
Front Screen ProtectionYes
Disconnect SwitchYes
Cesar Data TagYes
ROPS/TOPS/FOGS Certified CanopyYes
Technical Dimensions
Ground Clearance (mm)160
Length - Track (mm)1220
Length - Undercarriage (mm)1580
Kingpost Clearance (mm)410
Length - Cab/Canopy (mm)1430
Width - Cab/Canopy (mm)980
Height - Cab/Canopy (mm)1360
Height - Dump (Range) (m)2.64
Distance - Sprocket Idler Centres (mm)1210
Radius - Tailswing (m)1.1
Height - Dozer (mm)230
Width - Dozer (mm)980 - 1340
Width - Substructure (mm)990
Width - Over Tracks (mm)980 - 1330
Height - Track (mm)370
Width - Track (mm)230
Gauge - Track (m)0.75 - 1.11
Height - Dig (max) (m)3.67
Length - Boom (mm)1800
Reach - Digging (max) (m)4.04
Reach - Digging on Ground (max) (m)3.98
Depth - Dig Below Ground (m)0.23
Height - Dozer Above Ground (max) (m)0.24
Depth - Dig Dozer Up (m)2.42
Depth - Dig Dozer Down (m)2.58
Height - To Dipper Nose Pivot Pin (mm)3150
Radius - Front Swing No Offset (m)1.52
Radius - Front Swing Fully Offset (m)1.2
Length - Dozer Centre of Boss (mm)790
Counterweight Clearance (mm)430
Depth - Vertical Wallcut (m)2.14
Height - Over Canopy (mm)2340
Technical Specifications
Motor Type (Phase)3 Phase AC Permanent Magnet
Capacity - Hydraulic System (L)28
Capacity - Hydraulic Tank (L)15
Speed - Travel (Range) (mph)1.5 - 2.5
Power - Tractive (kN)13.2
Payload (t)1.5
Off-Board Fast Charge0-100% @ 415V 2.5 hrs
Output - Nominal (lpm)42 @ max rpm
Tearout - Bucket (max) (kN)18
Tearout - Dipper (max) (kN)9.1
Speed - Slew (rpm)7.9
Pressure - Ground Bearing (kg/cm2)0.36
Angle - Boom Swing Right (°)75
Angle - Boom Swing Left (°)55
Angle - Dipper Rotation (°)126
Angle - Approach (°)25.3
Angle - Bucket Rotation (°)201
Weight - With Long Dozer (kg)+9
Weight - With Mechanical Quickhitch (kg)+14
Weight - With Hydraulic Quickhitch (w/o hoses) (kg)+24
Weight - With Gravemaster Dipper (kg)+5
No. of Lower Rollers (per side)3
Pressure - Main Relief (bar)167 (Slew), 235 (Track)
Flow Rate - Hydraulic Aux (L)32
Operating Modes
L: 1200rpm
G: 1600rpm
H: 1800rpm
Pressure - Hydraulic Aux (bar)200
