53' Diesel Scissor Lift Stage V

Name: 53' Diesel Scissor Lifts Stage V | Sunbelt Rentals
SKU: 10002505

Product Code: 10002505

The 53' diesel scissor lift stage V offers outstanding versatility and height access for a range of construction and maintenance tasks. Equipped with advanced stage V diesel technology, this lift provides efficient performance while adhering to stringent emissions standards. With its robust build and user-friendly controls, it ensures safety and ease of operation, making it an ideal choice for both indoor and outdoor projects. Elevate your worksite capabilities with this reliable lifting solution. Product ID: 10002505

We'll pick the exact model you receive, as availability can change day-to-day.

They all perform to the same high standard, so whichever one you receive will do the job perfectly.

Choose a product


Hire dates:

Start date

End date

Selected hire period:

2 days

Product Description

The Dingli JCPT1823RT is a robust and versatile electric scissor lift, designed for efficient indoor and outdoor use. With its compact dimensions, it ensures easy manoeuvrability in tight spaces while providing a reliable working platform for various construction tasks. Ideal for maintenance and installation jobs.

Item ID: 50000070

Reference: 078007

Length (m)

4.88

Width (m)

2.27

Height (m)

2.49

Weight (kg)

9190 - 9520

All Motion Alarm

Yes

Non Marking Tyres

Yes

Power To Cage

Yes

Proportional Controls

Yes

All-Wheel Steering

Yes

Extended Platform

Yes

Fold Down Hinged Railing System

Yes

Self Locking Gate

Yes

Outriggers

Yes

Dual Flow Hydraulics

Hourmeter

Yes

Lifting Check Valves

Yes

Manual Descent

Yes

Oscillating Axle Chassis

Yes

Proportional Direct DC Electric Drive

Proportional Lift Up

Yes

Quad Holding Brakes

Single Pump Hydraulics

Yes

Slide-Out Engine Tray

Yes

Tilt Sensor

Yes

Area - Platform (m²)

7.2834

Ground Clearance (m)

0.30

Ground Clearance - Stowed (mm)

300

Height - Drive (m)

Height - Guardrail (m)

3.23

Height - Stowed (m)

3.19

Height - Working (m)

Length - Platform (m)

3.98

Size - Tyre

315

Turning Radius - Inside (m)

2.35

Turning Radius - Outside (m)

5.2

Wheelbase (m)

2.86

Width - Platform (m)

1.83

Height - Hand Rails Down (m)

2.49

Height - Platform (m)

Height - Working (max) (m)

Capacity - Fuel Tank (L)

100

Capacity - Hydraulic Tank (L)

130

Gradeability (%)

Load - Safe Working (kg)

680

No. of Lifting Eyes

No. of Persons (Max)

Slope (Max) (%)

Speed - Drive (Elevated) (mph)

0.68

Speed - Drive (Lowered) (mph)

3.79

Speed - Falling (Loaded) (s)

Speed - Rising (Loaded) (s)

Speed - Wind (max) (mph)

Tyre Type

Solid Non Marking

Drive Type

4WD

Output - Power

36.5kW (48.9hp)

Hydraulic System

Hydraulic oil cooler

Capacity - Total (kg)

680

Weight - Total Aerial Platform (max) (kg)

9190

Building Information Modelling (BIM)

Digital Download

View Model
