Horsepower (hp)125
Controller OptionsDSE 7320 controller
Frequency50Hz
Alternator TypeECP34-2S4 A
Autonomy15hrs @ 75% load (Prime)
Time - Operating (hrs)15.7
No. of Cylinders4
Volume - Swept (L)4.77
Speed - Engine (rpm)1500-1800
AspirationTurbo Charged
Displacement (L)4.77
Displacement (cm³)4770
Capacity - Engine Oil (L)15
Ratio - Compression18 : 1
Injection TypeDirect
No. of Poles4
Exciter SystemSelf-regulating brushless
Coupling TypeFlexible disc
Bearing TypeSingle Bearing sealed
Coolant TypeWater (Engine) / Direct drive centrifugal blower fan (Alternator)
Capacity - Coolant (L)16
Temperature - Exhaust Gas (°C)548
Current (A)100 (PRP) / 200 (MCB) / 200 (ATP)
Battery IsolatorStandard
ConnectionStar
Air Flow - Standby Intake (kg/hr)402
Air Flow - Standby Cooling (m3/min)3.3
Air Flow - Alternator Fan (m3/s)3.3
GovernorMechanical
FilterPaper Element
Consumption - Engine Oil0.00001
Capacity - Oil (L)15
Flow - Exhaust Gas @ Standby (m3/min)18.86
Back Pressure - Allowed (max) (mbar)10
Altitude (max) (m)5,000
Voltage - Alternator RegulatorAVR +/- 1.0%
No. of Batteries1
Volume - Shipping (Sea Ready) (m3)7.7
Material - HousingGalvanised steel canopy
Rating - MCB (A)200
Rating - ATP (min.) (A)200
Impact - Load (max) (kVA / kW)60 / 48
Capacity - Cubic (L)4.77
Recommended OilAPI CH4-SAE I0W40
Output - RPR Rating (kW)80
Output - Standby Rating (kW)88
Speed ControlMechanical governor
Power - Net Rated (kWm)88
Air Flow - Engine (m³/s)3.30
Size - Exhaust Discharge100
Capacity - Coolant HT (L)16
FinishTotal Protection +
Power - Starter Motor (kW)4.2
Output - Power80kW (PRP) / 88kW (Standby)
Air Flow3.3m3/min (Standby cooling)
402kg/h (Standby intake)
3.3m3/s (Alternator fan)
3.3m3/s (Engine)
