Horsepower (hp)123.4
Controller OptionsDSE 4520
Frequency50Hz
Alternator TypeECP34-2S/4
Autonomy21.6hrs @ 50% load (Prime)
15.2hrs @ 75% load (Prime)
11.5hrs @ 100% load (Prime)
10.2hrs @ 100% load (Standby)
No. of Cylinders4
Volume - Swept (L)4.765
Speed - Engine (rpm)1500
AspirationTurbo Charged
Displacement (L)4.765
Displacement (cm³)4765
Capacity - Engine Oil (L)14
Ratio - Compression17.2 : 1
Injection TypeDirect
No. of Poles4
Exciter SystemSelf-regulating brushless
Coupling TypeFlexible disc
Bearing TypeSingle Bearing sealed
Coolant TypeWater (Engine) / Direct drive centrifugal blower fan (Alternator)
Capacity - Coolant (L)18
Temperature - Exhaust Gas (°C)548
Battery IsolatorOptional
ConnectionStar
Air Flow - Standby Intake (kg/hr)470
Air Flow - Standby Cooling (m3/min)3.9
Air Flow - Alternator Fan (m3/s)0.32
GovernorMechanical
FilterTwo stage filtration
Consumption - Engine Oil0.00001
Capacity - Oil (L)14
Flow - Exhaust Gas @ Standby (m3/min)20
Back Pressure - Allowed (max) (mbar)100
Voltage - Alternator RegulatorAVR +/- 1.0%
No. of Batteries1
Volume - Shipping (Sea Ready) (m3)5.95
Material - HousingGalvanised steel
Capacity - Cubic (L)4.765
Recommended OilAPI CH4-SAE 10W40
Output - RPR Rating (kW)92
Output - Standby Rating (kW)101
Speed ControlMechanical
Power - Net Rated (kWm)92
Capacity - Coolant HT (L)18
FinishWinding Protection Grey
Power - Starter Motor (kW)4.2
Output - Power92kW (PRP) / 101kW (Standby)
Air Flow3.9m3/min (Standby cooling)
470kg/h (Standby intake)
0.32m3/s (Alternator fan)
