Horsepower (hp)72
Controller OptionsDSE 7320 controller
Frequency50Hz
Alternator TypeECP32-2M4 B
Autonomy23hrs @ 75% load (Prime)
Time - Operating (hrs)22
No. of Cylinders4
Speed - Engine (rpm)1500
AspirationTurbo Charged
Displacement (L)4.77
Displacement (cm³)4770
Capacity - Engine Oil (L)15
Ratio - Compression18 : 1
Injection TypeDirect
No. of Poles4
Exciter SystemSelf-regulating brushless
Coupling TypeFlexible disc
Bearing TypeSingle Bearing sealed
Coolant TypeWater (Engine) / Direct drive centrifugal blower fan (Alternator)
Capacity - Coolant (L)16
Temperature - Exhaust Gas (°C)511
Current (A)87 (PRP) / 100 (MCB) / 100 (ATP)
Battery IsolatorStandard
ConnectionStar
Air Flow - Standby Intake (kg/hr)301
Air Flow - Standby Cooling (m3/min)3.3
Air Flow - Alternator Fan (m3/s)3.3
GovernorMechanical
FilterTwo Stage Paper Element
Consumption - Engine Oil0.00001
Capacity - Oil (L)15
Flow - Exhaust Gas @ Standby (m3/min)13.43
Back Pressure - Allowed (max) (mbar)9
Altitude (max) (m)5,000
Voltage - Alternator RegulatorAVR +/- 1.0%
No. of Batteries1
Volume - Shipping (Sea Ready) (m3)7.7
Material - HousingGalvanised steel
Rating - MCB (A)100
Rating - ATP (min.) (A)100
Impact - Load (max) (kVA / kW)40kVA | 32kW
Capacity - Cubic (L)4.77
Recommended OilAPI CH4
Output - RPR Rating (kW)48
Output - Standby Rating (kW)53
Speed ControlMechanical
Power - Net Rated (kWm)54
Air Flow - Engine (m³/s)0.084
Size - Exhaust Discharge80
Capacity - Coolant HT (L)16
FinishTotal Protection +
Power - Starter Motor (kW)4.2
Output - Power48kW (PRP) / 53kW (Standby)
Air Flow3.3m3/min (Standby cooling)
301kg/h (Standby intake)
3.3m3/s (Alternator fan)
0.084m3/s (Engine)
