Horsepower (hp)80.5
Controller OptionsDSE 4520: Standard
Frequency50Hz
Alternator TypeECP32-2M/4 B
Autonomy31hrs @ 50% load (Prime)
21.4hrs @ 75% load (Prime)
17hrs @ 100% load (Prime)
15.6hrs @ 100% load (Standby)
No. of Cylinders4
Volume - Swept (L)4.765
Speed - Engine (rpm)1500
AspirationTurbo Charged
Displacement (L)4.765
Displacement (cm³)4765
Capacity - Engine Oil (L)14
Ratio - Compression17.2 : 1
Injection TypeDirect
No. of Poles4
Exciter SystemSelf-regulating brushless
Coupling TypeFlexible disc
Bearing TypeSingle Bearing sealed
Coolant TypeWater (Engine) / Direct drive centrifugal blower fan (Alternator)
Capacity - Coolant (L)16
Temperature - Exhaust Gas (°C)511
Battery IsolatorOptional
ConnectionStar
Air Flow - Standby Intake (kg/hr)367
Air Flow - Standby Cooling (m3/min)3.3
Air Flow - Alternator Fan (m3/s)0.2
GovernorMechanical
FilterTwo stage filtration
Consumption - Engine Oil0.001
Capacity - Oil (L)14
Flow - Exhaust Gas @ Standby (m3/min)14
Back Pressure - Allowed (max) (mbar)80
Altitude (max) (m)5,000
Voltage - Alternator RegulatorAVR +/- 1.0%
No. of Batteries1
Volume - Shipping (Sea Ready) (m3)5.74
Material - HousingGalvanised steel
Capacity - Cubic (L)4.765
Recommended OilAPI CH4-SAE 10W40
Output - RPR Rating (kW)60
Output - Standby Rating (kW)66
Speed ControlMechanical
Capacity - Coolant HT (L)16
FinishWinding Protection Grey
Power - Starter Motor (kW)4.2
Output - Power60kW (PRP) / 66kW (Standby)
Air Flow3.3m3/min (Standby cooling)
367kg/h (Standby intake)
0.2m3/s (Alternator fan)
